IBT
- High resistance with aluminium-titanium and light body
- 700 bar maximum operation pressure
- Repeatability of ± 3,0 %
- Torsion retaining ratchet system
- 360° adjustable reaction arm with safety lock feature
- 360° x 180° multi-positional swivel quick release couplings
- Suitable for continuous operation at maximum pressure
- Higher torques available on request
- Pressure relief valve prevents over pressure
| Type | Drive size | Torque [Nm] | Weight [kg] | Dimensions [mm] | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| min. | max. | A | BR | C | D1 | D2 | E1 | E2 | E3 | E4 | F | |||
| 07 IBT | ¾" | 110 | 1.100 | 1,8 | 42 | 21 | 66 | 56 | 88 | 68 | 114 | 25 | 111 | 54 |
| 1 IBT | ¾" | 180 | 1.800 | 2,5 | 50 | 26 | 72 | 70 | 105 | 85 | 140 | 29 | 145 | 67 |
| 3 IBT | 1" | 445 | 4.450 | 5,0 | 68 | 34 | 95 | 93 | 142 | 114 | 189 | 40 | 178 | 90 |
| 5 IBT | 1½" | 740 | 7.400 | 8,0 | 80 | 39 | 123 | 110 | 160 | 137 | 224 | 47 | 211 | 100 |
| 8 IBT | 1½" | 1.060 | 10.600 | 11,0 | 90 | 47 | 134 | 120 | 170 | 153 | 241 | 47 | 222 | 120 |
| 10 IBT | 1½" | 1.530 | 15.300 | 15,0 | 100 | 51 | 142 | 131 | 181 | 154 | 259 | 59 | 246 | 128 |
| 15 IBT | 2½" | 2.020 | 20.200 | 23,0 | 112 | 56 | 167 | 150 | 220 | 174 | 294 | 67 | 293 | 133 |
| 20 IBT | 2½" | 2.630 | 26.300 | 26,5 | 120 | 59 | 183 | 161 | 211 | 186 | 313 | 71 | 308 | 153 |
| 25 IBT | 2½" | 3.420 | 34.200 | 35,0 | 137 | 66 | 200 | 181 | 231 | 199 | 334 | 76 | 323 | 160 |
| 35 IBT | 2½" | 4.800 | 48.000 | 50,0 | 153 | 77 | 216 | 205 | 255 | 241 | 376 | 79 | 373 | 167 |
| 50 IBT | 2½" | 7.100 | 71.000 | 87,0 | 160 | 81 | 223 | 210 | 260 | 259 | 419 | 98 | 400 | 178 |
The lightweight alloy gives the IBT ultimate power with the smallest total weight. The standard square drive will fit customary sockets or other attachments. The torsion retaining pawl system achieves maximum efficiency as bolt torsion is restricted with each stroke, optimising direct preload force transmission.
Options
- Higher torques on request
- Personalized engraving on the housing (for example: company logo)
ACCESSORIES
Scope of delivery
- Hydraulic square torque wrench IBT
- Interchangeable support
- Torque table
- Calibration certificate
- Operation manual
- Tool case (to type 10 IBT)
