Series 7465
- Manual torque wrench with holder for insertion tools
- Torque range 1-1.500 Nm
- Scale accuracy ±4,0 %
- Double scale in Nm/ft.lb and Nm/lb.in (sizes 5-30 Nm)
- Clockwise and anti-clockwise tightening
- Audible and tactile signal when torque is reached
- Non-slipping metal handle
| Type | Drive size | Torque [Nm] | Weight [kg] | Dimensions [mm] | |||||
|---|---|---|---|---|---|---|---|---|---|
| min. | max. | A | B | C | D | E | |||
| 7465-5 | 9x12 | 1 | 5 | 0,36 | 235 | 253 | 190 | 25 | 18 |
| 7465-15 | 9x12 | 3 | 15 | 0,38 | 235 | 253 | 190 | 25 | 18 |
| 7465-30 | 9x12 | 6 | 30 | 1,022 | 277 | 295 | 227 | 25 | 18 |
| 7465-60 | 9x12 | 10 | 60 | 1,028 | 364 | 382 | 314 | 25 | 18 |
| 7465-100 | 9x12 | 20 | 100 | 1,035 | 370 | 389 | 320 | 25 | 18 |
| 7465-200 | 14x18 | 40 | 200 | 1,29 | 445 | 470 | 395 | 30 | 25 |
| 7465-340 | 14x18 | 60 | 340 | 1,5 | 585 | 610 | 535 | 30 | 25 |
| 7465-800 | 24x32 | 150 | 800 | 4,64 | 1.000 | 1.035 | 950 | 55 | 37 |
| 7465-1500 | 27x36 | 300 | 1.500 | 12,25 | 1.725 | 1.775 | 1.675 | 63 | 42 |
The manual torque wrench series 7465 has a holder for insertion tools and is adjustable in a torque range of 1-1.500 Nm. The matching insertion tools can be purchased as accessories. The sizes 5-30 Nm have a double scale with the units Nm/ft.lb and Nm/lb.in. An audible and tactile clicking signals the reached torque. Due to the non-slipping metal handle the manual torque wrench rests comfortably in the hand and ensures easy and safe tightening as well as loosening of bolted connections.
ACCESSORIES
Scope of delivery
- Manual torque wrench 7465
- Calibration certificate
- Operation manual
- Plastic pipe (up to size 340 Nm) or tool case (from size 500 Nm)
